Residential Yingli Solar Panels 4BB Cells MC4 Compatible With Connector

Product Categories
Suzhou Jun Hui Import and export trade Co., Ltd.
Contact Now

Residential Yingli Solar Panels 4BB Cells MC4 Compatible With Connector

Brand Name : Yingli/Jinko

Certification : ISO9001/CE

Place of Origin : China

MOQ : 50 Pieces

Price : Negotiation

Payment Terms : T/T、L/C、West Union

Supply Ability : 5000000 Watt/Watts per Month

Delivery Time : Shipped in 7 days after payment

Packaging Details : In well protected carton or wooden box with pallets. 26pcs per pallet, 380pcs fill into 20GP, 820pcs fill into 40HQ

Trademark : Yingli

Operating Temperature : -40° C~+85° C

Cable : 4mm&Sup2

Module Efficiency : 19%

Size : 1640*992*40mm

Connector : MC4 Compatible Connector

Solar cell : A Grade

Application : Residential/Commercial

Contact Now

YINGLI 10Years Warranty 4BB Solar cells Poly 260W 265W 270W Per Watt solar panel

Product Description

Module Type

DHP60-260

DHP60-265

DHP60-270

DHP60-275

Maximum Power (Pmax)

260W

265W

270W

275W

Open-circuit Voltage (Voc)

38.1V

38.3V

37.9V

38.5V

Maximum Power Voltage (Vmp)

30.6V

30.8V

30.9V

31.1V

Short-circuit Current (Isc)

9.01A

9.10A

9.22A

9.25A

Maximum Power Current (Imp)

8.50A

8.61A

8.73A

8.84A

Module Efficiency(%)

15.90%

16.21%

16.51%

16.82%

Power Tolerance

0~+5W

Standard Test Environment

Irradiance 1000W/m2, Cell Temperature 25℃,Spectrum AM 1.5

Product Details

Residential Yingli Solar Panels 4BB Cells MC4 Compatible With Connector

Glass

* High-transmittance and low reflection
* Inspection:GB15763.2-2005.ISO9050
* High solar transmittance
* High mechanical strength
* High flatness

Solar Cell


* High output-power: conversation efficiency is 18%-22%
* High shunt-resistance: adapt the several environmental conditions.
* Bypass diode minimizes the power drop by shade
* Excellent low light effect
* Low breakage rate

Residential Yingli Solar Panels 4BB Cells MC4 Compatible With Connector

Residential Yingli Solar Panels 4BB Cells MC4 Compatible With Connector

Frame

* Aluminium extrusion profile with prompt delivery

* Available in customized surface finish
* Excellent material for smooth and subtle edges
* Extrusion for construction and other industrial purposes
* Thickness variable according special request

Junction Box

* High current and voltage carrying capacity

* Simple, quick and safe effective field assembly
* IP 67 it can be used in the outdoor iron environment
* Expansion connector are available for future requirement
* Double permanent connection are adapted for all of the connecting.

Residential Yingli Solar Panels 4BB Cells MC4 Compatible With Connector

Line&Packing

Residential Yingli Solar Panels 4BB Cells MC4 Compatible With Connector

Project cases

Residential Yingli Solar Panels 4BB Cells MC4 Compatible With Connector

Payment

Payment Term

T/T

EXW

30% T/T in advance, balance paid before dispatch

FOB

CNF(CFR)

30% T/T in advance,

balance paid againist copy of B/L

CIF

L/C , Money Gram , Western Union , Paypal

Delivery Time

7-10 working days after down payment received


OUR Services :

1. Rich experience in manufacturing and exporting electric equipment.

2. High quality and competitive price.

3. Strict quality control and excellent after-sales service.

4. Manufacturing according to customers requirements is available.
